| Measuring object |
Liquid |
| Density range |
0.53 to 2.0 g/cm3 |
| Pressure range |
Up to JIS 30K class |
| Temperature range |
- 25 to + 400°C (Subject to different designs) |
Process
connection |
4" flange
(1" flanges for external chambers) |
| Construction |
| (1) |
Water tight construction: equiv. to IP 65 |
| (2) |
Flameproof construction: Ex d IIC T6 |
| (3) |
Intrinsically safe construction: Ex ia IIC T6
(EB3C intrinsically safe relay barrier is to be used.) |
|
| Alarm contacts |
1 point (High or Low)
1 x SPDT or 2SPDT (Equ. to DPDT) |
| Type of switch: |
Microswitch AC 250 V, 5A
General purpose, vibration proof and hermetic seal type |
|
| Material |
| Float, liquid contact material: |
SUS316, SUS316L, or Titanium |
| Flange: |
Carbon steel, SUS304, SUS316, or SUS316L |
| Housing: |
Aluminum alloy |
| Chamber: |
Carbon steel, SUS304, SUS316, or SUS316L |
|
| Accuracy |
±10mm (Density 1.0g/cm3) |
