FT-1000 |
FP-1000 |
| Type |
Float tape type |
Pipe seal type |
| Measuring object |
Liquids |
Liquids |
| Liquid density |
0.6 to 1.9 g/cm³ |
0.6 to 1.9 g/cm³ |
| Measuring range |
Min. 3m to Max. 25m |
Min. 3m to Max. 10m |
| Pressure range |
Max.3MPa
(Subject to different shapes due to pressure rating) |
Max.2MPa
(Subject to different shapes due to pressure rating) |
| Temp. ranges |
-196 to +400°C
(Subject to different shapes due to temperature rating) |
0 to +150°C
(Subject to different shapes due to temperature rating) |
| Materials |
| Float: |
SUS304(Opt. SUS316,SUS316L) |
| Measuring tape: |
SUS316 |
| Guide wire: |
SUS304(Opt. SUS316,FEP covered) |
| Indicator: |
ADC12(Opt. SCS13, SCS14) |
|
| Float: |
SUS304(Opt. SUS316,SUS316L) |
| Measuring tape: |
SUS316 |
| Guide wire: |
SUS304(Opt. SUS316,SUS316L, PVC) |
| Indicator: |
ADC12(Opt. SCS13, SCS14) |
|
| Process connection |
Tank top |
Tank top |
| Indication accuracy |
Std. ±3mm |
Std. ±10mm |
| The above data have been data by our test equipment(Max. 3m) under the conditions, dia.400Float,no transmitter, water, normal temperature, atmospheric pressure.The above-mentioned accuracy may not be obtained, depending on the diameter of float,installation conditions, and density of liquid. |
| Adaptive functions |
| Alarm transmitters: |
Output accuracy ±1%F.S., Max. 6 alarm point, Weather proof, Flame proof or Intrinsically safe |
| Electric transmitters: |
Output DC4 - 20mA, Output accuracy ±1%F.S., Weather proof, Flame proof or Intrinsically safe |
| Pneumatic transmitters: |
Output 20 - 100kPa, Output accuracy ±1%F.S. |
| Digital transmitters: |
Accuracy ±1mm, Additinal data of liquid temp, Alarm status etc, Weather proof, Flame proof or Intrinsically safe |
|
