UW 2000 Series

UW-2000 is a Ultrasonic Level Monitor for liquids with best cost performance.
Very small flow rate can be covered:  Min. 0 - 0.5 L/h [Water] can be measured.
 Alarm output option available:    In addition to local indication type, alarm output version is also available.
 Compact design:   Easy installation onto instrument panel.
 Safety for high temperature and pressure: All metallic material construction covers tough applications!


Measuring object Liquids (Temp. -20 to +60°C, Press. Atm)
Max .Range UW-2100 : 4.0 m (100 kHz, Blocking distance 0.24m)
UW-2200 : 9.99 m (50 kHz, Blocking distance 0.49m)
Indication accuracy ±0.25% (F.S.) or 1cm whichever larger
Output Level signal : 4 to 20mA DC
Alarm contact : PNP Open collector (H and L)
RS232C for adjustment only
Power supply 10.2 to 27.6V DC, Consumption Approx.3W
Material Body , Housing and sonic Membrane : PP (Polypropylene)
Sealing O ring : Fluorine rubber

Exclusive cable with water tight connector (10m) provided
